Atlas Copco Rotary Compressor Products Wholesale - Greeknhi Screw Air Compressor
Product details of the atlas copco rotary compressor
Product Introduction
The good-looking appearance of Greeknhi Screw Air Compressor atlas copco rotary compressor has caught attraction of more customers. The quality of the product is consistent with the requirements of international quality standards. Service is the main soft power for Xin Green Machinery (Fujian) Co., Ltd .
Features
Highly efficient cooling system
Greeknhi's GA series air compressor is designed with an operating temperature of 55℃, similar to a tropical desert environment. This series features an improved cooling system for controlling the operating temperature of the unit cooler, thus ensuring the air compressor will not fail during high temperature operations.
Three stage oil-gas separator
This three stage oil-gas separator is made independently by Greeknhi and has won a national patent. It includes three stages: centrifugation, sediment and filtration. It can provide high quality compressed air with an oil content less than 2ppm.
Original air end with large air capacity
The air compressor is equipped with asymmetric male and female rotors and they have two prominent advantages over the other rotors.As the gear tooth profile of the rotor consists of an arc and arc envelope, a "convex-concave" seal is achieved between the rotors, which helps to produce hydrodynamic lubricant film and make the compressor more efficient.Speed of this air compressor is 30-50% lower than that of other air compressors, due to the large rotor and bearing. The rotor and bearing also reduce noise, vibration and effects caused by impurities and carbides on the rotor and ensures a longer service life.
High quality air end bearing
Greeknhi GA series compressor uses SKF bearings. It features a stable operation and is applicable to variable working conditions, ensuring the motor a longer service life.
Special motor for air compressor
The highly efficient motor meets IE3 standards with an energy efficiency up to 93%.
Main technical data of GA series screw air compressor
| Model | Motor power | Working pressure bar | Capacity m3/min | Dimensions mm |
| GA7 | 7.5KW/10HP | 8 10 13 | 1.2 1.0 0.8 | 1000*700*1220 |
| GA11 | 11KW/15HP | 8 10 13 | 2.0 1.8 1.6 | 1200*750*1400 |
| GA15 | 15KW/20HP | 8 10 13 | 2.88 2.41 2.02 | 1250*750*1400 |
| GA22 | 22KW/30HP | 8 10 13 | 3.97 3.43 3.02 | 1250*750*1400 |
| GA30 | 30KW/40HP | 8 10 13 | 5.20 4.72 4.29 | 1650*850*1650 |
| GA37 | 37KW/50HP | 8 10 13 | 6.70 6.08 4.88 | 1650*850*1650 |
| GA45 | 45KW/60HP | 8 10 13 | 8.24 7.40 6.20 | 1650*850*1650 |
| GA55 | 55KW/75HP | 8 10 13 | 10.52 8.90 8.00 | 1850*1050*1800 |
| GA75 | 75KW/100HP | 8 10 13 | 14.36 12.02 10.34 | 2050*1050*1850 |
| GA90 | 90KW/125HP | 8 10 13 | 16.20 14.52 12.60 | 2050*1050*1850 |
Company Advantage
• Greeknhi makes effort to provide excellent services to meet the needs of customers.
• Our company has vigorously established several modest, steady and honest teams that are capable of controlling the market. It provides a solid foundation for our firm development.
• Our company enjoys great geographic location with different main transportation lines crossing the city. Besides, the unimpeded road condition provides strong guarantee for the successful transportation of products.
For bulk purchase of the products, please contact us.
Greeknhi is committed to the research and development,design, production,sales,installation, repair,maintenance and technical engineering consulting services of efficient and energy-saving air compression system and compressed air purification equipment.The main products of the company are screw air compressor,air dryer,air receiver tank,etc...
