Product details of the atlas copco oil injected rotary screw compressors
Quick Overview
Greeknhi Screw Air Compressor atlas copco oil injected rotary screw compressors is designed with the needs of the user in mind. atlas copco oil injected rotary screw compressors is great in the field with high-performance. It increasingly reflects its broad application areas and market prospects.
Product Introduction
Compared with other products in the same category, atlas copco oil injected rotary screw compressors has more advantages, specifically in the following aspects.
Features
Two stage compressor air end
This two stage compressor lowers the compression ratio compared with a single air compressor, reduces air leakage, bearing load and ensures a longer life service and volumetric efficiency of the air end. With our optimization, bearings have a life span of over 150,000 hours, and low noise, low vibration, safe and reliable operation is ensured.
Four-pole motor
As the motor speed is relatively low with 1480RPM (50HZ) as compared with that of the two-pole motor, there is air compressor wear and a longer service life.
Intelligent control system
Greeknhi's GA+VSD series intelligent control system is able to conduct remote control through computer interface and achieve simultaneous control for multiple compressors.
Split type
The air end and motor is connected separately, which is easier for installation, dismantlement and maintenance..
Backward curved centrifugal fan
An optional backward curved centrifugal fan uses an impeller to increase air flow. In addition, during the operation the centrifugal fan features no friction, low noise, no dust and easy maintenance.
Patent design of inlet valve
Sinking gravity sensor oil stop valve,effectively stops the oil reverse and largely reduces the inlet obstrucion loss.
Intelligent controller
Communication interface RS485 makes the distant control and joint control of multiple sets compressors come true.
Larger controller
Cooler on the side,designed for the users in tropical area,free from the failure of overheating.
Main technical data of GA+VSD series screw air compressor
| Model | Motor power | Working pressure bar | Capacity m3/min | Dimensions mm |
| GA22+VSD | 22KW/30HP | 8-13 | 0.7-4.15 | 1300*750*1400 |
| GA30+VSD | 30KW/40HP | 8-13 | 1.16-6.4 | 1650*850*1650 |
| GA37+VSD | 37KW/50HP | 8-13 | 1.54-7.25 | 1650*850*1650 |
| GA45+VSD | 45KW/60HP | 8-13 | 1.54-9.7 | 1650*850*1650 |
| GA55+VSD | 55KW/75HP | 8-13 | 1.54-12.5 | 1850*1050*1800 |
| GA75+VSD | 75KW/100HP | 8-13 | 2.52-16.5 | 2050*1050*1850 |
| GA90+VSD | 90KW/125HP | 8-13 | 2.52-20.5 | 2050*1050*1850 |
| GA110+VSD | 110KW/150HP | 8-13 | 3.77-24.5 | 2600*1660*1880 |
| GA132+VSD | 132KW/175HP | 8-13 | 3.77-28.0 | 2600*1660*1880 |
| GA160+VSD | 160KW/215HP | 8-13 | 4.0-33.6 | 2880*1780*2000 |
| GA200+VSD | 200KW/270HP | 8-13 | 10.0-43.0 | 3200*1780*2000 |
| GA250+VSD | 250KW/335HP | 8-13 | 10.0-54.0 | 3400*2120*2200 |
Company Introduction
Lying in Xin Green Machinery (Fujian) Co., Ltd is mainly engaged in the business of Rotary Screw Air Compressor, Atlas Copco Screw Compressor, Compressed Air Dryer in the industry. Close to the customer's needs, our company takes innovation to create a reasonable service plan for customers. Thus, we can build a harmonious relationship with customers, and create a better service experience for customers. Do not hesitate to contact us if you are interested in ourRotary Screw Air Compressor, Atlas Copco Screw Compressor, Compressed Air Dryer.
Greeknhi is committed to the research and development,design, production,sales,installation, repair,maintenance and technical engineering consulting services of efficient and energy-saving air compression system and compressed air purification equipment.The main products of the company are screw air compressor,air dryer,air receiver tank,etc...
